Classic Strap Single-Track Bypass Barn Door Hardware Kit, Brushed Nickel Finish

Sku: SBCLN4D
$283.00
$217.00

or 4 interest-free payments when you choose Sezzle at checkout

EXPERT ADVICE

Get the right advice from barn door specialists

FREE RETURNS

Free returns on all hardware & accessories

DO GOOD

We have 5 trees planted for each hardware kit sold

HERE TO HELP

We're available to help you from 8am - 8pm, weekdays on phone, chat & email

Single-Track Bypass Barn Door Hardware Kit by Rustic Rolling Doors

The Single-Track Bypass Barn Door Hardware kit is great for tight spaces where there is insufficient room on the sides of your opening for a traditional bi-part system.  With a single track, the bypassing door is held in front of the inner door by Z-shaped hangers, which allow the doors to be "stacked" when in the open position. The hangers overlap so both doors are always kept together with some overlap between them. Perfect for the bathroom, bedroom, den, closet, pantry or laundry room.



Features

barn door hardware track thickness

Sturdy Hardware

Heavy-duty 1/4" powder-coated steel tracks and hangers are built tough to last a lifetime
barn door hardware roller

Quiet Glide Wheels

Polymer nylon wheels so that your door glides along the track quietly and smoothly
barn door hardware spacer holes

16" On Center

Tracks are drilled at 16" on center to align with stud spacing for easy installation
barn door hardware door stop

Adjustable Door Stops

Customize the open/close position of your doors with adjustable door stops
barn door hardware components

All Parts Included

Includes everything you require to mount your doors (doors & handles not included)
barn door installation instructions

Easy Installation

Easy-to-follow written & video installation instructions to make installation a breeze
barn door hardware finish

Two Finish Options

Flat Black finish. For Brushed Nickel finish click HERE
barn door hardware warranty

5 Year Warranty

We offer a 5 year, "no questions asked" warranty on all hardware parts

Specifications

barn door hardware door thickness

Door Thickness

For doors 1-3/8" to 1- 3/4" thick. Click HERE if your doors are thicker or thinner
barn door hardware weight capacity

Weight Capacity

Built for a maximum weight capacity of 250lbs per door
barn door hardware track length

Track Length Options

Choose from track length from 4' to 20' long on the "Track Length" dropdown menu
bypass barn door hardware overhead clearance

Overhead Clearance

This kit requires 5-1/4" from top of door to ceiling for installation
bypass barn door hardware profile

Distance From Wall

Distance from wall to outside edge of outer door is 5-1/4"
barn door sizing

Barn Door Sizing

Recommended 2" of overlap between doors and between sides of doors and doorway. Click HERE for door sizing suggestions
barn door hardware soft close

Compatible Soft Close

Often purchased with this kit: compatible Soft Close Mechanisms
bypass barn door flush handle

Flush Handle

Recommended handles for Bypass Kits: Flush Handle

Configuration Options

bypass barn door hardware double door

2 Doors

Standard configuration. Single track, both doors stack on top of each other when pushed to the open position
bypass barn door hardware 3 door

3 Doors

A third door is added to the standard configuration. Two doors on the inside track and the 3rd door on top of the other door using offset hangers. The two doors using straight rollers do not bypass each other
bypass barn door hardware 4 door

4 Doors

Four doors on the track. The two outer doors overlap the using offset hangers. The front doors sit in front of the back doors when in the open position. Typically used for wide doorways or for dividing rooms

Resources

What's in the box?

Find out what components are included with your bypass barn door hardware kit

Installation Guide   Spec Sheets

Get the technical information you need before you purchase

Frequently Asked Question

Get the answers to our most frequently asked questions

Shipping & Returns

Shipping fee is $24. Ships within 3 business days via UPS. Click the icon to see our shipping & return policy

Installation Video
